/ Sys45 Onit module
Design: O/M
Adjustable spotlight with aluminium body for installation on Sys45 systems.
The spotlight can be rotated up to 90° horizontally and 330° vertically.
Accessories available separately and easily applicable after installation.
Adjustable spotlight with aluminium body for installation on Sys45 systems.
The spotlight can be rotated up to 90° horizontally and 330° vertically.
Accessories available separately and easily applicable after installation.
| Color temperature | 4000K | CRI | >80 | |
| Beam Angle | Spot 12° | LOR | 82% | |
| UGR | Colour deviation | |||
| Light source power | 10W | Life time | ||
| Light source flux | 1240lm | Control | 0,6Kg | |
| Light source efficiency | 124lm/W | IP rating | 20 | |
| Luminaire power | 12W | IK rating | ||
| Luminaire flux | 1020lm | Weight | ||
| Luminaire efficiency | 85lm/W | Wiring |
| Color temperature | 4000K |
| Beam Angle | Spot 12° |
| UGR | |
| Light source power | 10W |
| Light source flux | 1240lm |
| Light source efficiency | 124lm/W |
| Luminaire power | 12W |
| Luminaire flux | 1020lm |
| Luminaire efficiency | 85lm/W |
| CRI | >80 |
| LOR | 82% |
| Colour deviation | |
| Life time | |
| Control | 0,6Kg |
| IP rating | 20 |
| IK rating | |
| Weight | |
| Wiring |
Last Update: 1 January, 1970
/ Downloads
/ Accessories
/ Warnings
Choose the length and layout of the system exactly as you want it, to model the right lighting functions for different tasks. For further information please contact: support@om-light.com
For the specific supply of "DALI 2" drivers, please contact: support@om-light.com
